Production and development process

Located in Shenzhen, KAZ Circuit focus on providing one stop service including PCB manufacturing, PCB Assembly (SMT/DIP), Box Building and Testing.

The processed products cover many industries such as the Internet of Things, medical treatment, industrial control, communication, network, digital, security, transportation, smart home, etc.

KAZ Circuit is able to manufacture the PCBs from 1 to 50 layers.

Max PCB Board Size 600*1200mm

Min Trace Width/Space: 0.075mm (3mil) / 0.075mm (3mil)

Max Finished Copper Thickness: 12oz (420um) for out layer, 6oz (120um) for inner layer

DSP-1008+NPM-D3+CM212+JT NS1000+AOI(JTA-320-2M)

Fit Components Sizes:

Min: 0.2×0.1mm

Max: 50×50mm, Pitch=0.2mm

Supported Components:188 Tape, 20 Tray

Fit for Mobile phone, Motherboard, Industrial Control Board, Laptop, GPU, Etc.

DSP-1008+MX400+MX200+MX200+MX200P+JT NS1000+AOI(JTA-315-2M)

Fit Components Sizes:

Min: 0.4×0.2mm

Max: 45×150mm

Fit for Motherboard,Laptop,small & medium GPU, etc.

Supported Components:280 Tape, 20 Tray
